• Portable home battery designed for home backup
• 2016Wh capacity, Max. 2500W Load Power
• 2500W AC output for 99% appliances
• Plug & Play home backup solution
• Incredible Fast Charge, AC charging 1.6 hours to full charge
• Long-lasting LifePo4 battery supports up to 10 years
China Factory 2500W Lithium Battery Portable UPS Power Station Power Bank Generator For Home Outdoor Camping
Specs of LANPWR S2500 2500W Portable Power Station | |||
Item | Standards | Max | Remark |
Battery Type | 45AH | --- | LiFePO4,14 series 3 parallel single 15AH |
Rated Voltage | 44.8V | --- | 14s |
Battery Capacity | 2016WH | --- | Depends on the capacity of a single cell |
Rated Output Power | 2500W | ||
Input Voltage Range | 100V | 110V | |
Input Frequency Range | 50HZ | 63HZ | Under frequency stop charging |
Input Surge Current | 20A | ||
Constant Charging Power | 1300W | 1500W | |
Charging Power Switching | 1300W | ||
Charging Cut-off Power | 70W | ||
UPS Mode | Load <2000W long-term work | UPS mode load load < 2000W, long-term work, and continuous 100W charging, switching time 10MS | |
EPS Mode | Load <2500W long-term work | EPS mode load load < 2500W long-term work, total input ≤ 1500W. When the load power is 1000W, the charging power is 500W |
|
USB-A Output | USB-A QC3.0 *3: 5V, 3.37A; 9V,2.00A; 12V,1.5A |
18W Max per port | |
USB-C Output | PD100W*3: 5V,3A; 9V,3A; 12V,3A; 15V,3A; 20V, 5A |
100W Max per port | |
PPS output voltage range | 20V | ||
Car Charging | Support | 12V charging current is 10A, over 15V, charging current is 20A | |
MPPT Solar Charging | Support | Supports up to 700W solar charging | |
Output Waveform | Pure Sine Wave | Rated resistive load | |
AC Charging and Discharging | Support | ||
Overload Protection | 2650W | 2700W | When the output is overloaded, it will work for about 5 seconds, and the buzzer will stop to prompt a continuous alarm sound and the screen will display |
50 seconds automatic shutdown | |||
Fan on Temperature | 60℃ | 65℃ | After the temperature of the heat sink reaches this range, turn on the fan and the screen will display |
Fan off Temperature | 45℃ | 50℃ | After the heat sink temperature reaches this range, turn off the fan |
Charging Power Error | 5% | 7% | The error is too large and needs to be controlled within 3% |
Discharge Power Error |
5% |
A: This product uses high-quality lithium iron phosphate batteries.
A: The AC output port of the D5-2500 has high power ratings and maximum power topower most household devices. it is recommended to check the power of the equip-ment before use to ensure that the total power of all loaded equipment is lower thanthe rated power.
A: The liquid crystal display screen of the D5-2500 will show the remaining power, and the equipment with stable general electricity can be estimated according to the time.
A: Working time = 2160Wh* 0.89 / operating wattage of your device.
For reference, assuming power consumption of your device is 60W (might be a laptop), working time will be 2160wh*0.89/60w≈32hrs (rough calculated) .
Tips: Actual power consumption varies from different usages, please consult LANPWR for better purchase decision.
A: When charging, the LCD screen will display the remaining power, the power indicator ring outside the battery power percentage will start to flash, and the input power display will indicate the charging status.
A: Please wipe the D5-2500 with a dry, soft, clean cloth or paper towel.
A: When storing, please turn off the D5-2500 firstly, and then store in a dry, ventilated place at room temperature. Do not place the D5-2500 near water sources. For long-term storage, it is recommended to discharge the battery to 30% and then charge it to 60% everv three months to extend the service life of the D5-2500.
A: No, D5-2500 cannot be carried on the plane.
A: The D5-2500 adopts an air-cooled cooling system with built-in fan to help heat dissipation, so slight noise is normal during use.(Around 50-60dB)
A: lt is normal for the D5-2500 to have a slightly hot while charging/discharging. The D5-2500 is in line with national safety standards. You can use it at ease.
A: If the D5-2500 is used in the process of warning prompt and Didi alarm sound, the several reasons shall be excluded, such as buzzer alarm and flashing triangle symbol for high temperature protection, low temperature protection, over discharge protection, over charge protection, overload protection, short circuit protection and over current porotection, and the D5-2500 can be restored to normal work after being excluded in several aspects. lf an alarm occurs during the use of the D5-2500 and the alarm icon does not disappear after restarting the device, please stop using the D5-2500 immedi-ately (do not charge or discharge the device).
If the information above cannot solve your problem, please contact customer service for consultation.
A: Please confirm whether the inlet and outlet of the D5-2500 are unblocked, remove the cause and automatically resume use after the temperature decreases.
